PCB Spring Terminal Blocks Connector
PH5.08mm PCB Spring Terminal Blocks Connector
Detail
Rated:300V,10A
Dielectric strength:AC1500V/1 Minute
Insulation Resistance:1000MΩ Min
Contact Resistance:20mΩ Max
Wire Range:14~22AWG
Strip length:10mm
Temp.range:-40°C~+105°C
MAX Soldering:+260°C,5s
Housing Material:PA66(UL94 V-0)
Contact:Brass,Tin plating
Reed:Stainless seel
