NON-ZIF1.25mm(0.049")

1.25PH H=3.0mm NON-ZIF

Detail

Specifications :
1.Housing:High-Temp Plastic,UL94-V
Color:White or Black
2.Locker:High-Temp Plastic,UL94-V
Color:White or Black
3.Contact:Phosphor Bronze
Initial:30m 0hms Max.
Voltage Rating:50V AC,DC
4.Solder Tab:BRASS
5.Temperature Rating:-25°C~+85°C
6.Dielectric Withstanding Voltage:500V AC/Min
