Material:
1.Housing Material:PBT,PA66,PA46(UL94V-0)
2.Contact Material:Round Pins-0.46mm Diameter Phosphor Bronze;Gold Plating Over Nickel
Electrical:
1.Voltage Rating:125 VAC Rms
2.Current Rating:1.5 AMP
3.Contact Resistance:30 Milliohms MaX
4.Insulation Resistance:500 megohms min @500V DC
5.Dielectric Withstanding Resistance:1000V AC Rms 60Hz. 1Min
6.Durability:750 Cycles Min
7.Temperature:-40°C / +85°C
